WLAN Component of Smart Network Commander RUIJIE RG-SNC-Pro-WLAN-EN
- Ruijie RG-SNC (Smart Network Commander) is a network management system launched by Ruijie Networks especially designed for network performance management and configuration. With a friendly browser UI, the SNC provides an extensive array of features such as network topology display, device management, performance monitoring, configuration & software management, real-time alarm and log & report management.
- Included 10 RG-SNC-Pro-EN-license.
Specifications
| RG-SNC WLAN Component | |
| Topology Management | Support viewing of all wired and wireless devices on one single topology. |
| Surveillance Statistics | Support accessibility and alert statistics for all wireless ACs and APs. |
| Support user trend statistics for the whole network, hotspots, single AC and APs. Support online user statistics for hotspots, single AC and APs. | |
| Support logout rate statistics for the whole network, hotspots and single AP. Support setting a time range for logout rate statistics. Support viewing of Top N logout rate statistics. | |
| Support idle AP statistics for the whole network. Support viewing of Top N idle APs on a daily or monthly basis. | |
| Support uplink and downlink rate statistics/Top N viewing for all hotspots and APs. Support trend statistics for single hotspot, AP uplink and downlink rates. | |
| Support surveillance indicator customization. | |
| Device Management | Support viewing of the following information in AP: wireless radio table, device information, originating AC and hotspot, SSID, alert statistics, etc. |
| Support statistics of AP online user trend, bandwidth utilization trend, CPU/memory utilization trend and STA association failure causes. | |
| Support radio on/off setting of AP. | |
| Support manually adding, deleting and auto discovery of AC. | |
| Support connecting AC to Web network control and Telnet management. | |
| Support viewing of the following information in AC: device panel, device information, device status, management AP, SSID and alert statistics. | |
| Support AC statistics on current user trend, bandwidth utilization trend and CPU/memory performance trend. | |
| Wireless User Management | Support viewing of wireless user MAC, IP, online status, online duration, uplink/downlink rates, signal strength and device type. |
| Support viewing of user online/offline records including time of occurrence, action, user IP, WLAN ID, SSID, associated AP, originating AC, etc. | |
| Support real-time surveillance on designated devices for uplink/downlink traffic trend and signal strength. Data update frequency <=5s. | |
| Support designating several terminals as key end devices with operation quality surveillance. Issue alerts when packet retransmission rate exceeds the designated threshold. | |
| Issue alerts when abnormal behavior is found in the key end devices. Such events include offline, association/online failure, etc. | |
| Support viewing of end device statistical graphs of designated user group (hotspot). Minimum requirement: present the graphs in terms of band (2.4G, 5G), connection protocols (802.11a/ 802.11b/ 802.11g/ 802.11n/802.11ac/802.11ax). | |
| Spectrum Analysis | Support >=8 spectrum analysis: current interference table, spectrum diagram, real-time FFT diagram, FFT occupation ratio diagram, spectrum density diagram, channel occupation ratio diagram, channel occupation ratio trend diagram and power trend diagram. |
| Device Configuration Management | Support configuration of AC system attribute, WLAN, security, interface, trap/syslog servers, etc. |
| Support synchronization of AC blacklist. | |
| Wireless Tracking | Support tracking of end device, authentication user, AP, AC, rogue AP based on IP, MAC, login user name, real user name, device name, SSID, AP location or hotspot name. |
| Rogue AP Management | Support rogue AP table including rogue AP BSSID, SSID, channel, signal strength, vendor, finder AP and its location, single AP mode, countermeasure status, etc. |
| Support AP operating mode and rogue AP countermeasure status statistics. | |
| Support graphical configuration of AP operating mode (graphical guidelines for AP operating mode configuration). | |
| Support setting of blacklist and whitelist. | |
| Hotspot Heat Map Management | Support import, export and manual editing of hotspot information. |
| Support existing APs management based on hotspots. Support statistics of SSID associated with hotspot, logout rate, associated user count and uplink/downlink rates. | |
| Support floor plan import in .jpg, .png or .gif format. Support setting AP location on the floor plan and viewing of AP coordinates. | |
| Support setting different kinds of obstacles. Support setting AP height and deployment scenario. | |
| Support viewing of AP information, AP user information on heat map and adjusting AP channel. | |
| Support heat map generation based on signal strength, rate, channel conflict (2.4G/5GHz). | |
| Alert Management | The product should be built-in with a variety of wireless alert categories. Support alert category customization based on the actual demand whenever necessary. Provide a minimum of 10 common syslog alert customization lists. |
| The product should be built-in with a variety of wireless alert categories. Support alert category customization based on the actual demand whenever necessary. Provide a minimum of 15 pre-defined trap alert customization lists. | |
| Hierarchical Management | Support AC, hotspot and SSID management based on hierarchy and categorization. |
| Report Management | Customize task for long-term surveillance of the network performance. Support report generation on a real-time or periodic basis. |
| Support report creation, search, editing and deletion. Support report online viewing, import/export, etc. Support periodic export and regular publishing. | |
| Support history report search. | |
| Support report data filtering based on AC, hotspot or SSID. | |
| Integration of Topology and User Information | To protect customer's early investment, support registration integration with SAM/SMP. Support searching of online user table including user name, IP address, MAC address, etc. |
| Compatibility | The product should support standard SNMP MIP management base. Support management on mainstream vendor standard MIB device. |
| Certification | The product should be compliant with the related rules under Administration of Software Products Regulation. With national software copyright registration certificate. |
